Load Flow Analysis for Canadian Facilities

Load flow establishes the steady-state picture: voltage at each bus, how heavily transformers and conductors are loaded, and where real capacity exists. In Canada it is also where the provincial dimension first appears, because the Canadian Electrical Code is adopted province by province and the authority reviewing your installation differs with it.

Free Consultation
CSA Z462IEEE 1584CCOHS CompliantCEC Standards

What a Canadian Load Flow Study Establishes

The result is a validated model. Short circuit, coordination and CSA Z462 arc flash assessment all build on it.

What We Deliver

Voltage profile across the system

Steady-state voltage at every bus under the load combinations that matter, including worst case rather than the design case alone, which is where marginal conditions actually appear.

WHAT GOES WRONG

Where Load Flow Studies Mislead

A load flow is straightforward to produce and straightforward to produce wrongly. The failures are in the inputs, and they are invisible in the output.

  • Single line taken from drawings and never verified on site.
  • Utility service data assumed rather than obtained from the provincial utility.
  • Only the design load case run, with no worst-case combination.
  • Conductor lengths estimated, distorting voltage drop on long runs.
  • Standby generation and transfer arrangements left out of the model.
  • Results reused years later without accounting for load added since.
Contact Us
Load flow analysis for a US industrial power distribution system
Load flow analysis report from Carelabs

THE OUTCOMES

What the Report Contains

The report hands back a validated model alongside the results, because the model is what makes the next study cheaper and the arc flash assessment after it defensible.

  1. 1Single line verified against the installation
  2. 2Bus voltages under each load case modelled
  3. 3Transformer and conductor loading against rating
  4. 4Available headroom for planned additions
  5. 5Province and code variant recorded
  6. 6The validated model, for reuse downstream
Reach Out

How We Run a Canadian Load Flow Study

01

Confirm province and utility

Identify the provincial authority and the serving utility, and request service data rather than inferring it from the installed switchgear.

02

Verify the single line

Walk the installation, reconcile drawings against what is installed, and record conductor sizes, lengths and nameplate ratings.

03

Define the load cases

Establish which load combinations to model, including worst case and any standby or transfer configuration the site runs.

04

Model and validate

Run each case and treat non-convergence or implausible voltages as data problems to resolve before accepting output.

05

Report and hand over the model

Results and headroom with assumptions, plus the validated model so short circuit and coordination build on it.
