How to Perform a Power Quality Analysis in Colombia?
Electrical arcs arise when a gas is subjected to a voltage greater than its insulating qualities. When the voltage is strong enough to ionize the air between the conductors, the arc is initiated. When a gas is ionized, it turns into an excellent conductor, enabling current to flow and creating the arc-shaped current known as arc flash. An arc fault is an unintended electrical discharge that produces a fire.
- Elevated temperatures caused by an arc flash produce dazzling light and deafening noise.
- An arc blast is a high-pressure wave that may expel molten metals and fragments.
- Toxic fumes
Arc flash dangers may have catastrophic effects on companies and electrical infrastructure. Among the commercial losses caused by arc flash dangers are:
- Additional expenditures for medical care, rehabilitation, worker’s compensation, and costs associated with accident investigation and production downtime.
- Litigation-related legal fees and judgements, penalties, insurance premiums, repair and replacement personnel expenses.
- Negative influence on the company’s name and reputation.
- Loss of business possibilities resulting from a history of accidents, which might lead to the revocation of an electrical license.
Causes of Electrical Arc Flash:
- Insulation of a conductor that has failed
- Human negligence
- Improper maintenance of switches and circuit breakers
- The presence of water close to the equipment is problematic.
- Unplug panels that are occluded.
- High-voltage wiring
- Ionization discharge
- Defective tools and equipment
Arc Flash Analysis Methodology:
Arc flash risks can arise whenever high-voltage or low-voltage, high-current switching occurs.
Step 1: Determine the Risk of Arc Flash:
- Conduct an arc flash/fault study or analysis, including data collection, software-based power system modelling, short circuit analysis, overcurrent protective device coordination study, arc flash analysis, and arc flash assessment.
- Evaluation of the chance that a worker may be exposed to an arc flash
Step 2: Manage the Threat:
- Interacting exclusively with de-energized equipment to reduce worker exposure to arc flash dangers.
- Manual systems should be replaced with automated ones.
- Install physical barriers between employees and energized machinery to protect them from potential dangers.
Step 3: Engineering Control:
- Reduce incident energy by decreasing short circuit current.
- Detection and suppression systems for arc flashes
Changing and distant controls
- Upgrades or modifications to the switchboard
- Installing permanent circuit breakers
- Insulating material for bus bar
- Alteration of blown fuses
Step 4: Administrative Controls:
- Labeling switch rooms, plants, and other sites to detect incident energy levels.
- Arc border designation
- Documenting arc flash data and diagrams.
- Providing precautionary strategies and processes to reduce exposure
- Implementing incident energy and PPE (Personal Protective Equipment) levels
Step 5: Personal Protective Equipment (PPE):
- Despite being the least effective, personal protective equipment may lessen the severity of an accident but cannot prevent it. Personal protection equipment (PPE) is selected based on the energy levels of the occurrence.
CareLabs has a remedy for all your arc flash-related dangers. Well-trained and experienced professionals can evaluate arc flash hazard hazards, offer appropriate mitigation, and control strategies to protect your employees and property.
CareLabs Service Benefits:
- More secure electrical systems in conformity with regulatory norms and requirements.
- Fully integrated power systems are cost and time efficient.
- Establish a safer working environment
- In an emergency, provide solutions that can be implemented quickly.
- Increase safety margins
- Save time by automatically creating arc flash labels and work permits.
- Avoid potential penalties and legal expenses.
CareLabs has crew members stationed in many places to ensure that our professionals are close by in case of a regular or urgent situation. CareLabs has rapidly established itself as an ISO 9001:2008-accredited organization and collected a clientele with a formidable reputation and excellent comments. In all major cities, including São Paulo, Rio de Janeiro, Brasília, and Salvador CareLabs provides arc flash investigation and analysis services.
