Harmonic Analysis of Swedish Power System

harmonic-1

Power is an essential part of life in the contemporary world. The majority of the everyday items we use are powered in some form. To provide electricity to people in a secure and equitable manner, we must use the most advanced power technology currently available. Harmonics increase the loss by increasing the RMS value of the circuit’s current flow. As a result, there have been a variety of problems with the electrical systems. Harmonics affect both the loads and the entire distribution network. Harmonics may also damage delicate office and industrial apparatus and equipment. Harmonic flaws might not always be obvious right away, and it could be difficult to distinguish them from normal wear and tear.

An Explanation of Harmonic Distortion

Owing to its small size, the power supply may be less reliable owing to harmonic issues. Harmonics in electric current and voltage damage power systems. When there are many harmonics in the power supply, equipment may malfunction or fail. A nonlinear load typically introduces harmonics, or variations in the current waveform’s structure, into an electrical system. Devices include personal computers, powered motors, fax machines, laser printers, switch-mode power supplies (SMPS), batteries, and uninterruptible power supplies cause nonlinear loads and harmonics in power systems.

Why Is Harmonic Analysis Required?

Harmonics cause a decrease in the efficiency and dependability of electrical systems. If you use harmonic analysis to locate harmonics in your power system, your system’s reliability will increase. When the use of power electronics equipment increases, non-linear currents are produced. The system’s needs caused harmonics to be produced. Energy efficiency criteria must be followed, and equipment must use less electricity.

At What Point Did Harmonic Analysis Start to Matter?

  • If the total load or bus system readings are higher than 25% of the total load, the harmonic limitations need to be looked at.
  • To address issues with harmonics, such as equipment failure or damage.
  • When will the plant be extended, and by how many non-linear loads?
  • Harmonic analysis is necessary whenever an extra capacitor bank is added to the electrical systems.
THE DESIGN OF THE EQUIPMENT   A LEISURELY CONCLUSION.
Rotating apparatus. Cable resistance rises in addition to power loss, overheating, and pulsating torque
It is important to have power lines, a switchboard, and a transformerThere may be an issue if there is overheating, heavy use, overloading the neutral, or power interruptions.
Electric capacitors.  Unintentional occurrences frequently occur in the news
Using electricity   Insufficient effort
Protecting relays   Terrible habits and difficult journey

When a sinusoidal waveform interacts with a nonlinear load, distortion and harmonic production occur. Harmonic analysis is usually necessary to determine whether there are harmonics present in a system

Positive Effects of Reducing Harmonics in the Power System:

  • Harmonic analysis reduces operational costs by reducing the amount of energy lost through cables, switch gears, and safety devices. It also helps to reduce losses in the power supply.
  • By reducing the RMS current in the power system and removing extra transformers, it helps to lessen the need for cable, switchgear, and busbars.
  • When losses are minimized and the RMS current value is decreased, performance automatically rises. Harmonics increase losses and raise the RMS value of current in addition to overheating cables, transformers, motors, and capacitors. The unfavorable consequences can compel you to cancel an operation or result in financial loss.

How to Perform a Power Quality Analysis:

  • To illustrate non-linear loads, use a single-line graph.
  • Beware of the PCC, also called the point of common coupling or the point of common connection.
  • It is important to identify the buses inside the structure that might be harmed by harmonics.
  • As much information as you can about nonlinearly loads, and the previous harmonic performance of the power provider should be gathered.
  • Create a model using the ETAP (Electrical Transient Analysis Program) program and performance data for the electrical system.
  • Check the levels of voltage, current, and harmonic distortion. If the harmonic distortion is too severe, pick a remedy.
  • Perform a second harmonic analysis to verify CEC compliance once the mitigation approach has been put in place.

Modern technology is made available to CareLabs‘ staff members so they can ensure the safety of your electrical equipment and give you a secure workspace. Find out more about the harmonics research and analysis services offered by CareLabs by requesting a quote right away.
