The quality of the power supply has a direct impact on how the distribution network-connected equipment runs. It is expected that the equipment will function as intended and that its useful life will be about equal to the value provided. Similarly, it is expected that the network is reliable enough to prevent problems such as poor output or loss of functionality from occurring. There are several issues with the power system. These power quality issues, no matter how long they exist, can harm equipment. It is critical to maintain excellent power quality to protect equipment from breaking down.

This blog will discuss the research that must be conducted to assess the quality and reliability of power. Following that, several power quality systems and methods for measuring both the effect and the control are investigated. The implications of power quality disruptions are not at once visible, as opposed to the effects of reliability, which deal with long-term power outages. Even though, in certain circumstances, the repercussions of a power quality interruption are felt at once due to malfunctioning equipment or a delay in a process. This is especially true for brief noises like sags and breaks. In other circumstances, the impacts of a change in power quality may not be clear for some time. One example is when equipment fails. In this case, equipment deteriorates over time without anybody realizing. In other circumstances, power quality issues will result in more losses that are absorbed as part of the day-to-day costs of conducting business and go unnoticed.

What Happens When the Electricity Goes Out?

The following are the direct economic consequences:

  • The output loss
  • There are additional charges associated with restarting a procedure.
  • Repair and replacement costs for damaged equipment
  • More pauses and starts
  • People are concerned about their health and safety.
  • Costs incurred because of contract violation
  • Fines for failing to care for the environment.
  • Utility bills increased because of the outage.

The following are some of the indirect economic consequences:

  • The expenses incurred by a business because of delayed revenue or income.
  • How much money does losing market share cost?
  • How much does it cost to restore brand value?

Among the socioeconomic effects are:

  • An increase in a building’s temperature that might impair performance, health, or safety.
  • A personal injury or concern
  • If the change in power quality is not noted, it might result in electrical danger.

Finding the Fundamental Reasons of Poor Power:

The voltage, frequency, and waveform of a power supply system indicate whether it meets power quality criteria. However, several factors influence the quality of power. This blog discusses the following power quality issues:

  1. Voltage consistency
  2. Unbalanced voltage
  3. Electricity harmonics
  4. Flickering or changing voltage
  5. Voltage decreases, commonly known as “dips,” and power outages

Other less common phenomena, such as swells, transients, interharmonics, and noise, have received less study.

1. Voltage consistency

Voltages that remain constant for a long time (minutes or hours) are called steady-state voltages. The major impacts of long-term high voltage levels (overvoltage) or low voltage levels (undervoltage) include equipment failure, increased energy consumption by equipment, and probable system failure.

2. Unbalanced voltage

Unbalanced voltage often leads to increased losses, particularly in induction and three-phase motors.

  • This produces the inverse torque and wears out the bearings.
  • More stator and rotor heating
  • Installation cables can carry less current.
  • On the neutral conductor, more losses occur.
  • More energy is lost in wires.

3. Electricity harmonics

Almost all energy consumers generate harmonic currents and feed them into the power system. Harmonic currents are alternating currents with frequencies that are multiples of 50 hertz, also known as the fundamental frequency. Harmonic currents are typically generated by nonlinear electronics such as computers, variable speed drives (VSD), and discharge lights. Harmonic currents can cause significant harm to the installation and electrical grid. Harmonic, among other things, can damage components, installation parts, component loading, poor use of the installation’s current carrying capacity, shorter component life spans, and inefficient operation of protective components.

4.Flickering or changing voltage

The envelope of a voltage waveform is modified to make it flicker. It causes the light intensity of incandescent lights to vary in a predictable way. This regular variation in the amount of light flowing out might give some individuals headaches, make them less productive, and, in rare situations, trigger seizures.

5. Voltage decreases, commonly known as “dips,” and power outages

Voltage sags and interruptions do not harm most equipment, but longer disruptions frequently cause equipment to trip and lose output. One thing that can be asserted in general is that the expense of a long interruption is not proportional to its duration. It follows a logarithmic curve instead. People claim that the following factors have a significant impact on the expense of a protracted interruption:

  • The cost difference between a one-second, one-minute, and one-hour disruption, for example, is said to be modest in the manufacturing business.
  • The date, time, and location of the event (weekday, weekend, daytime, nighttime)

The value of customer reliability (VCR) is used by AEMO to calculate how much disruptions cost all users. Despite these figures reflecting how much consumers are prepared to pay to prevent an interruption, this willingness to pay is most likely tied to the actual cost. According to these estimations, a one-second outage costs around 20% of what a one-hour outage costs.

How Can Power Quality Issues Be Maintained to a Minimum?

CareLabs provides a variety of power quality services to identify and assess power quality issues. They are as follows:

  • Load Flow Analysis: This analysis is performed depending on how the system is used. It forecasts the quantity of power flow, voltage, power factor, and system losses.
  • Harmonic analysis is the technique of searching for and predicting potential harmonic issues using computer algorithms. Ways to cut back are also advised depending on the results.
  • Surge and Transient Analysis: This research investigates the causes of surges and transients.
  • Voltage Dips and Climbs Analysis: This analysis would monitor the voltage’s short-term drops and rises, as well as its value and course.
  • Study of Reactive Power: This analysis will determine the optimal reactive power at the distribution and load ends.
  • Captive Power Analysis: This research would determine how much captive power is required to satisfy demand while reducing energy surcharges and fuel use.

CareLabs studies and analyses power quality using the ETAP (Electrical Transient Analysis Program) program. It is the best piece of software for calculating and modelling all components of an electrical system to ensure equipment safety. We provide power quality analysis services in Oslo, Bergen, Trondheim, and Stavanger, among other significant cities. CareLabs strives to provide you with the finest service possible to make your electrical installation better and more dependable. Contact us today to book a power quality study or to get a quotation.
