Custom Relay Coordination Solutions For Indonesian Industries
Isolate faults, protect equipment, and stay compliant with Care Labs’ meticulous protective device coordination study in Indonesia. Carelabs models your facility's protective devices in ETAP and plots time-current coordination curves so each relay and breaker trips in the correct sequence when a fault occurs.
Free ConsultationOne scheme, several sites, no shared baseline
Operations spread across multiple locations typically have protection set by whoever commissioned each site. There is rarely a common standard, and rarely any record of what was actually applied.
What We Deliver
A common as-found baseline
Settings are read out of the devices at each location and recorded in one register, which for multi-site operators is frequently the first time the installed position has existed as a single document.
WHY IT MATTERS
Every site set by a different hand
Without a common baseline, a technician moving between locations encounters different philosophies at each. Maintenance error becomes likely, and no one can say whether any given site discriminates correctly.
- Settings read from each device rather than transcribed from documentation, because the two routinely disagree after years of undocumented adjustment.
- Fault levels established per site from the supplying network, since the same equipment behaves differently on a strong and a weak connection.
- Grading verified against calculated fault current at each position rather than against generic curves supplied with the device.
- Restoration behaviour assessed, as simultaneous re-energisation after an interruption produces a condition no single-circuit calculation reveals.
- Every recommended change reported with its arc flash consequence, so selectivity is not obtained at an unexamined safety cost.
DELIVERABLES
What you receive
Issued against PUIL 2011 and SNI IEC 60364, signed by the engineer who performed the grading.
- 1A consolidated as-found settings register covering every site assessed
- 2Time-current curves per grading path with the achieved margin annotated
- 3Discrimination register naming each failing pair and the fault range where it fails
- 4A settings philosophy applied consistently where site conditions allow, with deviations documented
- 5Recommended settings with a verification checklist for application at each location
How the study runs
Establish what exists
Settings are read at each location and consolidated into a single register, which is usually the first complete record the operator has held.
Establish fault levels per site
Supply fault level is obtained for each connection, since sites on different parts of the network present very different conditions.
Model each installation
Manufacturer characteristics are built for every installed device, including intentional delays configured into electronic trip units.
Grade and compare
Discrimination is calculated per site and results are compared, which identifies both genuine differences and inconsistencies with no technical basis.
Set a common philosophy
Where conditions allow, a consistent approach is recommended across sites, with documented exceptions where supply conditions genuinely require them.
Issue and verify
Settings are issued per site with a verification checklist, so the applied position is provable at each location rather than assumed.
