Free ConsultationWhy the capacitors keep failing
Power factor correction capacitors installed on a distorted network do not simply wear out. They are destroyed by current they were never rated to carry, and replacing them identically schedules the next failure.
What We Deliver
The resonant point located
A frequency scan of the modelled network shows where the capacitor bank and the supply transformer resonate, and how close that frequency sits to an order your plant actually produces.
WHY IT MATTERS
Replacing the symptom, repeatedly
The usual sequence is a failed bank, an identical replacement, another failure, then an assumption that the units are poor quality. Each replacement is a capital decision taken without the measurement that would explain it.
- Frequency scan performed before any capacitive equipment is specified, since adding capacitance to a resonant network amplifies distortion rather than correcting it.
- Each switching stage assessed separately, because the resonant frequency moves with the connected capacitance and a partial stage can be the dangerous one.
- Capacitor current measured with its harmonic content, establishing the actual duty rather than assuming the nameplate describes it.
- Supply impedance taken from the network operator's fault level, as resonance depends on it and it changes when the network is reinforced.
- Fuse and switchgear duty in the bank reviewed, since harmonic current affects them as well as the capacitors themselves.
DELIVERABLES
What you receive
Issued against STN 33 2000 and the applicable distortion limits, with the measurement and modelling basis stated.
- 1Frequency scan showing impedance against frequency, with resonant points identified per switching stage
- 2Measured capacitor current including harmonic content, compared against rating
- 3Measured network distortion with the full spectrum
- 4A detuning or filtering specification sized against the measured spectrum and network impedance
- 5An explanation of the failure history in terms of the measured conditions
How the study runs
Collect the failure history
What failed, when, and in which switching configuration. The pattern frequently points at the resonant stage before any instrument is connected.
Measure the bank and the network
Distortion at the point of supply and current into the capacitor bank are recorded together across a representative period.
Establish supply impedance
The network operator's fault level is obtained, since resonance depends directly on source impedance and cannot be modelled without it.
Scan every stage
A frequency scan is run for each switching configuration, because the resonant point moves with connected capacitance.
Size the remedy
Detuning or filtering is specified against the measured spectrum and the actual impedance rather than from a standard selection table.
Report and explain
Findings link the measured conditions to the failure history, so the recommendation is understood rather than simply followed.
